평균 반사율은 250 nm ~ 400 nm 에서 86% 를 초과합니다.

Specifications

Product Code

PAUV

Dimensions

Square: ☐±0.25 mm

Round: Ø 0/ 0/–0.25 mm

Thickness

t±0.25 mm

Parallelism

3 arc minutes

Clear Aperture

90% of edge dimension or diameter

(85% for PAUV PAUV-PM series)

Coating

UV -enhanced aluminum

Average Reflectance

≥85% (250 – 600 nm)

Substrate Material

N-BK7

Wavelength Range (nm)

250 – 600 nm
